Overview#

This widget allows users to create bookmark collections and store items in these collections. Collections can also be parented, meaning a collection’s child can be either another collection or an item.

This widget relies on a listener found in the model to update its content.

alt text

In order to use this widget, you will need to use an implemented version of the model when creating the widget.

Implementation#

The widget uses multiple components:

  • an item class

  • a model class

  • a delegate class

Item class#

the ItemBase class inherits directly from ui.AbstractItem but should not be used directly. Instead, the various children classes should be used to display items in the tree:

  • CreateBookmarkItem

  • TemporaryBookmarkItem

  • BookmarkCollectionItem

  • BookmarkItem

These items are the structures that will be used in the delegate to display UI items on screen.

Model class#

This class inherits from ui.AbstractItemModel and should also not be used directly. Instead, an implemented version of the model should be used. See: omni.flux.bookmark_tree.model.usd.

The ui.TreeView uses the model class to populate the tree. The class holds all the items of type ItemBase mentioned in the “Item class” section.

The model is also the class that will take actions on your collections (edit USD, created folders in your OS, etc.)

Delegate class#

This class inherits from ui.AbstractItemDelegate. The delegate will define how the ItemBase items should be displayed in terms of UI. The existing delegate can be overridden or replaced completely depending on your needs.

Implementation example(s)#

Please check:

  • omni.flux.bookmark_tree.model.usd

For implementation examples.
